Ergo

ERGO™ VDE Insulated Slotted Screwdrivers with 3-Component Handle 2.5 mm-12 mm

SKU
BE-8010S - BE-8065S
Product Details
  • Screwdriver developed according to the scientific ERGO™ process
  • ERGO™ insulated VDE screwdriver for slotted head screws
  • For work on live equipment, up to 1000 V, high quality blade insulation moulded directly onto the blade
  • Black oxide tip for higher accuracy
  • Three-component handle for maximum user comfort, soft material with ridged surface provides superior grip and greater force transmission
  • Maximum comfort with minimum effort due to the ergonomic design
  • Easy to choose the right tip with the colour-coded handle and permanent symbol on the domed end
  • No colour identification in extra small handle, sizes 2.5, 3.0, 3.5
  • Flat face to prevent it from rolling away
  • Integrated hanging hole
  • Size 10 and 12, in double shape handle for use with both hands for maximum torque power
  • High-performance alloy steel blade
  • Individually inspected and manufactured according to IEC 60900, tested in a water bath at 10000 V
  • Standards: ISO 2380/DIN 5264
Documents
Technical Details
Screw Yellow Tip 1000V IEC60900 1000V TRI VDE GS
Grouped product items
Product Buy online
BE-8010S 0.4 mm 2.5 mm 75 mm 17 mm 103 mm 178 mm 30 g
BE-8220S 0.5 mm 3.0 mm 100 mm 17 mm 103 mm 203 mm 33 g
BE-8230S 0.6 mm 3.5 mm 100 mm 17 mm 103 mm 203 mm 33 g
BE-8050S 1.0 mm 5.5 mm 125 mm 27 mm 122 mm 247 mm 62 g
BE-8255S 1.2 mm 6.5 mm 150 mm 36 mm 122 mm 272 mm 105 g
BE-8065S 1.2 mm 8.0 mm 175 mm 36 mm 122 mm 297 mm 127 g
Download Download
